It is an 8.5-meter pure electric city bus designed to meet the demands of urban public transportation. Combining advanced electric vehicle technology with passenger - friendly design, it offers an efficient, eco - friendly, and comfortable travel experience.
Parameter
Optional Configurations & Components
|
Front Axle |
5T disk type |
|
Rear Axle |
9.5T disk type |
|
Steering System |
Integrated electro-hydraulic booster pump |
|
Braking System |
Oil piston type air pump, dual-circuit air brake, front/rear disk brakes |
|
Tyre |
255/70R22.5 |
|
Battery |
210 kwh |
|
Motor Cooling Mode |
Intelligent cooling system |
|
Charge Rate |
1C |
|
Cooling Mode |
Liquid Cooling |
|
Driving System |
PM synchronous motor |
|
Manufacturing Enterprise |
CRRC Electric Vehicle |
|
Rated/Peak Power (kW) |
95/175 |
Feature
1)Dimensions and Structure
With dimensions of 8550x2500x3280 mm, it features a fully - loaded body structure, providing stability and durability.
The air suspension (2 front and 4 rear) ensures a smooth ride, minimizing vibrations and shocks.
2)Safety Features
The front axle is a 5T disc - brake type, and the rear axle is a 9.5T disc - brake type, providing reliable braking performance.
The bus is equipped with 255/70R22.5 tires, and the approach/departure angle is 9/9, enhancing safety during driving and maneuvering.
Product characteistic
1)Power and Performance
Powered by a pure - electric system, it is equipped with a motor having a rated power of 95 kW and a peak power of 175 kW.
The 210 kWh battery enables a driving range of 300 km, making it suitable for daily urban routes. It can reach a maximum speed of 69 km/h and has a maximum climbing gradient of 15%.
2)Capacity and Accessibility
It has a rated passenger capacity of 70, with seating for 14 - 28 passengers. The first - class tread is less than 380 mm, facilitating easy boarding, especially for the elderly and disabled.
Overseas Case
Electric Buses Deployed To Improve Accessible Transportation
https://www.yangtseauto.com/news/electric-buses-deployed-to-improve-accessible-85177981.html
These eco-friendly vehicles made by Yangtse aim to revolutionize public transport and feature dedicated accessibility, including ramps for wheelchairs, designated spaces for mobility devices, and CCTVs for passenger safety.
Developed in collaboration with PWD members of SLP associations, the buses were designed with direct input from the community they serve to ensure the buses meet their specific needs.
